Wire Rope Hoists

Name: Wire Rope Hoists
Brand: CHHAWCHHARIA ENGINEERING PRIVATE LIMITED
Price: 45000 INR
Availability: InStock

Price 45000 INR/ Piece

Get a Price/Quote

MOQ : 1 , , Piece

Wire Rope Hoists Specification

Trolley Travel Speed
20 m/min

Crane Traveling Speed
15-20 m/min

Recommend Power
3-30 kW (Varies by model)

Feature
Durable, Corrosion Resistant

Crane Total Weight
As per capacity (Contact supplier)

Condition
New

Material
Mild Steel / Alloy Steel

Crane Type
Wire Rope Hoist

Application
Industrial, Construction, Warehousing

Span Length
As per requirement

Loading Capacity
Up to 10 Ton

Lifting Time
As per model

Lifting Capacity
1-10 Ton

Lifting Height
6-30 m

Control Type
Pendant/Remote Control

Limit Switch
Provided

Emergency Stop
Yes

Voltage
380V-440V, 3 Phase, 50Hz

Protection Class
IP55 for motors

Drum Length
As per lifting height

Wire Rope Construction
6x37 or 8x19 SWG

Hoist Speed
4-8 m/min (Depend on model)

Color
Yellow/Blue (Standard)

Motor Type
Squirrel Cage Induction Motor/Failsafe Brake Motor

Operating Temperature
-10°C to +50°C

Hoist Mounting
Fixed, Motorized Trolley, Push Trolley

Rope Diameter
8-19 mm (Varies with capacity)

Insulation Class
F Class

Hoist Type
Electric, Double Girder or Single Girder

About Wire Rope Hoists

Experience a gilt-edged lifting solution with our marvelous Wire Rope Hoists, engineered for both single and double girder configurations. Select models offer resplendent versatility, with rope diameters ranging from 8 to 19 mm and hoist speeds of 48 m/min. These hoists utilise squirrel cage induction or failsafe brake motors, protected to IP55 and insulated to Class F. With an instant checkout option, you can obtain this corrosion-resistant, durable equipmentcrafted from mild or alloy steel and finished in vibrant yellow or blueideal for heavy-duty industrial applications up to 10 tons. Utilise the available offer for a swift procurement experience.

Versatile Applications and User Profile

Wire Rope Hoists are extensively used by professionals in industrial, construction, and warehousing environments. The application method is straightforward: mount the hoist on a fixed structure, utilize the motorized or push trolley system, and raise or lower loads on surfaces such as steel beams or girders. Control is seamlessly achieved via pendant or remote, making them suitable for a wide array of surfaces and settings where robust lifting is non-negotiable.

Export Markets, Samples, and Ordering Process

Wire Rope Hoists enjoy a substantial export demand across Asia, Africa, and global markets. Sample units are available; a sample policy details terms prior to issuance. Upon submitting a purchase order, samples can be handed over promptly, ensuring comprehensive evaluation before committing to bulk procurement. Once finalized, full shipments are delivered in adherence to international trade standards, ensuring excellence from order placement to doorstep delivery.

FAQs of Wire Rope Hoists:

Q: How do I select the right Wire Rope Hoist for my application?

A: To choose an appropriate hoist, assess your required lifting capacity, operating environment, and preferred hoist type (single or double girder). Also consider factors like rope diameter, hoist speed, mounting type, and control method (pendant or remote). Consulting with the supplier ensures the ideal model for your specific industrial or construction needs.

Q: What are the main benefits of using an electric Wire Rope Hoist?

A: Electric Wire Rope Hoists provide efficient, reliable lifting with robust durability. Their corrosion resistance, easy-to-operate pendant/remote control, and advanced safety features, such as limit switches and emergency stops, make them ideal for demanding environments requiring consistent performance.

Q: Where can Wire Rope Hoists be utilised most effectively?

A: These hoists are best deployed in industrial, construction, and warehousing settings where efficient and secure load handling is critical. Their adaptable mounting options allow installation on various beam or girder surfaces, ensuring flexibility across multiple infrastructure projects.

Q: What is the process for obtaining a sample before placing a bulk order?

A: Simply contact the supplier or exporter with your requirements, and submit a purchase order for a sample unit. Samples are quickly handed over according to the sample policy, allowing for thorough testing prior to confirming a larger order.

Q: How does the instant checkout feature streamline the purchasing process?

A: By providing instant checkout, the supplier enables customers to rapidly select and secure products, reducing turnaround time. This feature helps ensure timely delivery and hassle-free transactions, especially beneficial for urgent industrial and construction needs.

Q: What protection and safety features are included with these Wire Rope Hoists?

A: Each hoist is equipped with advanced protection (IP55 for motors, Class F insulation), durability features, and built-in safety controls like limit switches and emergency stops to guarantee secure operations during all lifting tasks.
